Mode A: offline point code import

Mode A is for suppliers with no API capability. You hand point codes to Waffo Point Topup as Excel/CSV files, Waffo Point Topup imports them into the inventory system, and the storefront, payment, and delivery all run on the Waffo side.

Advantages

No API development required
Simple and straightforward
Quick to get started

Limitations

Requires manual point code CSV file delivery
Inventory needs periodic replenishment

Integration flow

Mode A offline point code import flow: supplier provides a CSV, Waffo imports inventory, the user pays, and the point code is emailed to the user

Point code CSV format

Provide point codes in the following Excel/CSV format:

No.	Field name	Description	Required	Example
1	`skuId`	SKU identifier, provided by Waffo Point Topup	required	`SUPPLIER_POINT_001`
2	`pointCode`	Point serial number or code	required	`ABCD-1234-EFGH-5678`
3	`faceValue`	Face value	required	`1000`
4	`amount`	The point code price	required	`1000`
5	`currency`	Currency code	required	`JPY`
6	`expiryDate`	Expiration date, if applicable	optional	`2026-12-31`
7	`batchNo`	Batch number for tracking	optional	`BATCH_20250105_001`

Sample CSV:

skuId,pointCode,faceValue,amount,currency,expiryDate,batchNo
SUPPLIER_POINT_001,ABCD-1234-EFGH-5678,1000,1000,JPY,2026-12-31,BATCH_20250105_001
SUPPLIER_POINT_001,EFGH-5678-IJKL-9012,1000,1000,JPY,2026-12-31,BATCH_20250105_001
SUPPLIER_POINT_002,MNOP-3456-QRST-7890,3000,2900,JPY,2026-12-31,BATCH_20250105_001

Purchase link integration

After Waffo Point Topup imports the point code CSV file, you receive a purchase link to embed on your website. Link format:

https://{supplier}.waffoplay.com/{site_code}/

Example:

<!-- Simple link -->
<a href="https://supplier.waffoplay.com/jp/">Buy Points</a>

<!-- Button style -->
<button onclick="window.location.href='https://supplier.waffoplay.com/jp/'">
    Purchase Credits
</button>

Mode A needs no signature and no API integration. Users are redirected straight to the Waffo Point Topup payment page.

Settlement and reporting

Waffo Point Topup provides regular settlement reports containing:

Total points sold and total amount
Revenue breakdown by SKU
Remaining inventory status
Settlement amount

Next steps

Mode B: point code retrieval API

To retrieve point codes in real time and stop delivering files manually, see Mode B.

Integration overview

Full mode comparison and the preparation checklist.
